Electronic Crane Scale

About Electronic Crane Scale

• Crane scale Features

  • Microncontroller board digital electronic board with aluminum body
  • Large and bright LED display
  • Long battery life
  • Remote key use
  • Overload warning with buzzer
  • Stainless steel made hook for high strength and safety.
  • Overload safety 200%
  • Date and time feeding option
  • Weight measurements storage up to 100 values
  • Automatic zero tracking
  • Software linearity correction
  • Display hold
  • Power saver by display switch off option

  Crane scale Technical Data

  • Power230V AC + 10% 50 HZ
  • Designed On Advanced Micro Controller Technology
  • Temperature Range:  10^oC to 50^oC
  • Optional : 6V / 4 AH Rechargeable Dry Battery
  • 100,000 Internal Resolution
  • 12.5 MM LED Display
  • Safe Overload Up to 200% of Rated Capacity
  • Sensor : High Quality Load Cell
  • Ultimate Overload Up to 300% Of Rated Capacity

  Our Various Models (CRANE SCALE SERIES - Multi-function)

  Model No.	Capacity	Accuracy	Pan Size
  SWIC100	100 Kg	10 gm	Heavy Duty Hook
  SWIC200	200 Kg	20 gm	Heavy Duty Hook
  SWIC300	300 Kg	50 gm	Heavy Duty Hook
  SWIC500	500 Kg	50gm	Heavy Duty Hook
  SWIC1000	1000 Kg	100 gm	Heavy Duty Hook
  SWIC2000	2000 Kg	200 gm	Heavy Duty Hook
  SWIC3000	3000 Kg	500 gm	Heavy Duty Hook
  SWIC 5000	5000 Kg	500 gm	Heavy Duty Hook
  SWIC 10000	10000 Kg	1 Kg	Heavy Duty Hook
  SWIC 15000	15000 Kg	2 Kg	Heavy Duty Hook
  SWIC 20000	20000 Kg	2 Kg	Heavy Duty Hook
  SWIC 25000	25000 Kg	5 Kg	Heavy Duty Hook

  Crane scale Applications

  • Measure accurate magnitudes of metallurgical additives needed for the exact quantity of molten metal measured.
  • Prevent metal waste from furnace by measuring the actual magnitude required.
  • Prevent overloading of crane above its capacity.

  Crane scale Specification

  • Capacity: 50 kg -100 MT
  • Reading ability: 5gm - 20 kg
  • Power supply: DC adopter 9 volts
  • Power consumption : 6 W
  • Service temperature: 10^oC - 40^oC
  • Display size: 30 mm
  • Battery: Inbuilt 6V/ 4Ah rechargeable battery
  • Battery backup : 40 hours
  • Load cell: Made from high strength alloy steel
