Weighing Balance

Name: Weighing Balance
Brand: SWISSER INSTRUMENTS PVT. LTD.
Price: 7500
Availability: InStock

Get a Price/Quote

MOQ : 1 Piece

Weighing Balance Specification

Connectivity Type
Wired

Usage
Laboratory, Industrial, Retail

Interface
RS232 Serial Port

Features
Overload Protection, Low Battery Indicator, Auto Power Off

Application
For accurate weight measurement of goods and materials

Display Type
Backlit LCD Display

Function
Weighing, Tare, Zero, Unit Conversion

Automatic Grade
Automatic

Size
Approx. 250mm x 300mm Platform

IP Rating
IP54

Battery Life
Up to 60 hours (backlight off)

Power Source
AC and Battery Operated

Product Type
Electronic Weighing Balance

Weighing Scale Type
Bench Scale

Material
Stainless Steel Platform, ABS Housing

Power Supply
AC Adapter, Built-in Rechargeable Battery

Monitor Display
Digital LCD

Load
1g to 30kg

Accuracy
1g

Capacity Range
Up to 30kg

Color
White & Blue

About Weighing Balance

Weighing Balance

We are engaged in providing our clients with Electronic Weighing Scale that is widely used in construction, defense and education areas. These products are designed in compliance with international quality norms & standards, using premium raw material and latest technology. All our products are also checked and tested by expert quality controllers on various parameters to ensure flawlessness. We also provide customization as per the specifications laid down by the customers.

SPECIFICATION

Operating Temperature: 10°C to 60°C.
Storage Temperature : -10°C to 60°C.
Humidity: 10% to 95 % relative.
Power Supply :230 Volt / 50 Hz ± 5%.
Battery Backup: In Built Battery Backup (6 V Or 12 V Maintenance Free Sealed Battery).
Power Consumption : Less than 10 Watts.
Display: 7 Segment Bright LED Display /LCD Display.
All Models & Designs Are Subjected to Change.All Models Are Approved by Department of Weights & Measure, Govt. Of India.

Features:-

Advanced Micro controller Based System.
Overload Protection for Safety.
Most Precise and Best Quality Components.
Stainless Steel Pan.
Bright ( Red / Green) LED Display.
Multi Function Series With All Most Useful Functions Like Gram, Tola, Carat, Piece Counting Liter, Memory Accumulation, Auto Zero Tracking, Auto Off, Sensitivity Setting, Alert / Check Weight, G - Define, Intensity Adjustment, Running Character Display.
Auto Calibration
Liter / Kg Conversion.
Stand by mode For Long Time Backup (Battery Saving).
AC / DC Indicator.
RS 232 Port For Computer / Printer Interfacing.
Hook Facility Available For Suspended Weighing As Per Requirement.
Dual Display On 360° Revolving Pole or Back side For Easy Reading.

Applications :

Jewellery
Laboratories
Chemical, Pharmaceutical Industries
School & Colleges
Packing Units

Precision and Functionality Combined

The bench weighing scale delivers high-precision measurements from 1g to 30kg, making it perfect for goods and materials requiring accuracy in laboratory, industrial, and retail environments. With a large platform size, fast stabilization time, and user-friendly interface, this scale ensures efficiency and reliability in daily operations.

Designed for Demanding Environments

Engineered to endure challenging conditions, the weighing balance offers a working range from 0C to 40C and humidity tolerance up to 90% (non-condensing). Its IP54 certification assures resistance to dust and moisture, while the stainless steel platform and ABS housing provide durability and easy cleaning.

Flexible Power and Connectivity Options

This model includes both AC adapter power and a built-in rechargeable battery, supporting portable or stationary use for up to 60 hours. An RS232 serial port allows seamless data transfer to printers or computers, and reservation for custom print formats ensures integration with your workflow.

FAQs of Weighing Balance:

Q: How is the weighing balance calibrated?

A: The weighing balance is designed for external calibration, meaning calibration weights (not included) are used to ensure precise measurement accuracy. Follow the user manuals instructions to perform routine calibration as needed.

Q: What environments are suitable for using this weighing scale?

A: This scale is well-suited for laboratories, industrial applications, and retail settings. It can operate in temperatures from 0C to 40C and humidity levels between 10% and 90% RH (non-condensing), and features IP54 protection against dust and moisture.

Q: When should I use the tare and unit conversion functions?

A: Use the tare function to reset the scale to zero after placing a container, ensuring only the weight of the contents is measured. The unit conversion feature allows you to switch between different units, accommodating diverse application needs.

Q: Where can the weighing balance be installed?

A: Install the bench scale on a flat, stable surface in any laboratory, industrial site, or store. Its compact size (platform: 250mm x 300mm) and rugged construction make it adaptable to various workspaces.

Q: What benefits does the rechargeable battery offer?

A: The built-in rechargeable battery provides up to 60 hours of operation (with backlight off), enabling uninterrupted weighing tasks even during power outages or when used in field locations without AC access.

Q: How does the scale prevent errors or damage during use?

A: Overload protection safeguards the weighing mechanism from excessive weight, while a low battery indicator and auto power off feature help extend the scales lifespan and preserve accuracy.

Q: What is the process for connecting the scale to external devices?

A: With its RS232 serial port, the scale connects easily to printers or computers for data transfer. The reservation for custom print formats supports personalized reporting and integration into your data management systems.
