Magnet Base Scale

Name: Magnet Base Scale
Brand: SWISSER INSTRUMENTS PVT. LTD.
Price: 21500
Availability: InStock

Get a Price/Quote

MOQ : 1 Piece

Magnet Base Scale Specification

IP Rating
IP54

Automatic Grade
Automatic

Function
Weighing/Counting

Features
Magnetic Base, Low Battery Indicator, Overload Protection, Tare Function, Portable Design

Interface
RS232 (optional)

Power Source
AC/DC Adapter, Rechargeable Battery

Usage
Industrial/Commercial

Battery Life
Up to 72 hours (on full charge)

Application
Shops, Warehouses, Industrial Weighing

Size
300 x 300 mm Platform

Connectivity Type
Wired

Display Type
Digital (LED/LCD)

Product Type
Magnet Base Scale

Weighing Scale Type
Digital Platform Scale

Material
Mild Steel/ABS

Power Supply
230V AC / Built-in Rechargeable Battery

Monitor Display
LED Numeric/Backlit LCD

Load
Up to 150 kg

Accuracy
10 g

Capacity Range
30 kg to 150 kg

Color
Blue & Black

Platform Material
Anti-rust Stainless Steel Pan

Overload Capacity
150% of Rated Capacity

Operating Temperature
0C to 50C

Pan Size
300 x 300 mm

Calibration
External

Mounting Type
Freestanding (Magnet Base)

About Magnet Base Scale

Operating Temperature.: 10C to 60C.
Storage Temperature. : -10C to 60C.
Humidity: 10% to 95 % relative.
Power Supply :230 Volt / 50 Hz 5%.
Battery Backup: In Built Battery Backup (6 V Sealed Maintenance Free Battery).
Power Consumption : Less than 10 Watts.
Display: 7 Segment Bright LED Display .
All Models & Designs Are Subjected to Change.
All Models Are Approved by Department of Weights & Measure, Govt. Of India.
Feathers :-
Advanced E.M.F.C. Based System.
Glass Metal Wind Shield For Stable Better Performance.
Easy Operation With Feather Touch Membrane Keys.
Most Precise and Best Quality Components.
Stainless Steel Pan.
Bright Clear (Red) LED Display.
Port for external display.
Multi Function Series With All Most Useful Functions like Memory Accumulation, Auto Zero Tracking, Auto Off, Fill mode.
Auto Calibration
Multi Weighing Units Like Gram, Tola, Carat, Piece Counting, Percentage Weighing GSM Measurement [g/m2].
Stand by mode For Long Time Backup (Battery Saving).
AC / DC Indicator.
Standard Bi Directional RS 232 Port for Computer / Printer Interface.
Application :

Laboratories
Chemical,Pharmaceutical Industrirs
School & Colleges, Institutions for Experiments
Research & Development For Analysis

Robust Design for Demanding Environments

Built with a rust-resistant stainless steel pan and rugged mild steel/ABS construction, this scale withstands harsh industrial and commercial settings. The 300 x 300 mm platform supports loads from 30 kg to 150 kg, ensuring reliable performance for a variety of weighing needs.

Advanced Features for User Convenience

The magnetic base provides stable, freestanding operation, while overload protection and tare functionality enhance safety and usability. The bright digital display allows easy reading, and the low battery indicator helps avoid downtime. Rechargeable battery power delivers portability for field or remote use.

Versatile Power and Connectivity

Operate the scale on 230V AC power or take advantage of the built-in rechargeable battery for up to 72 hours of continuous use. Optional RS232 interface supports seamless data integration with other devices, making this scale suitable for both standalone and networked operations.

FAQs of Magnet Base Scale:

Q: How do I calibrate the Magnet Base Scale?

A: Calibration of the Magnet Base Scale is performed externally. Follow the manufacturers instructions, using certified calibration weights suitable for the capacity range. For best results, calibrate the device in its intended operating environment, between 0C and 50C.

Q: What are the main benefits of the anti-rust stainless steel pan?

A: The anti-rust stainless steel pan resists corrosion, ensuring durability and hygiene in both industrial and commercial settings. Its smooth surface is easy to clean, making it ideal for weighing a variety of items without contamination.

Q: When should I use the overload protection feature?

A: The overload protection feature automatically activates when the load exceeds 150% of the rated capacity. This safeguards the scale from potential damage and ensures accurate results even under heavy usage.

Q: Where can the Magnet Base Scale be installed?

A: This freestanding scale is designed for use on flat, stable surfaces in shops, warehouses, and industrial areas. Its IP54 rating allows it to function reliably in environments with moderate dust and water exposure.

Q: What is the process for switching between AC power and battery operation?

A: Simply connect the scale to a 230V AC outlet for continuous operation, or unplug to use the built-in rechargeable battery. The automatic switchover function ensures uninterrupted performance and maximum battery efficiency.

Q: How can I utilize the RS232 interface on this scale?

A: The optional RS232 interface allows you to connect the scale to computers, printers, or other peripherals for recording and managing weighing or counting data. This feature is particularly useful in automated or networked industrial systems.

Q: What distinguishes this scales weighing and counting functionality?

A: Apart from standard weighing, the scale is equipped with a counting function that simplifies inventory or batch processing. This saves time by calculating quantities efficiently, making it ideal for commercial and industrial inventory management.
