Digital Weighing Scale

Name: Digital Weighing Scale
Brand: SWISSER INSTRUMENTS PVT. LTD.
Price: 6000
Availability: InStock

Get a Price/Quote

MOQ : 1 Piece

Digital Weighing Scale Specification

Usage
Retail, Grocery, Laboratory

Features
Overload Protection, Large Platform, Quick Reading, Energy Efficient

Size
Approx. 245mm x 190mm x 60mm

IP Rating
IP20

Display Type
Backlit LCD

Automatic Grade
Automatic

Interface
User Button Interface

Application
Weighing, Counting

Battery Life
Up to 72 Hours (Rechargeable)

Function
Weight Measurement, Tare, Auto-Zero Function

Power Source
Electric and Battery

Product Type
Digital Weighing Scale

Weighing Scale Type
Table Top Scale

Material
Stainless Steel and ABS Plastic

Power Supply
AC 220V, 50/60Hz; Rechargeable Battery

Monitor Display
LCD Digital Display

Load
Up to 30 kg

Accuracy
1 g

Capacity Range
1 g to 30 kg

Color
White and Blue

About Digital Weighing Scale

Model No.	Capacity	Accuracy	Pan Size
SWII 002	2 Kg	0.2 gm	240 mm X 190 mm
SWII 031	3 Kg	0.1 gm	240 mm X 190 mm
SWII 005	5 Kg	0.5 gm	240 mm X 190 mm
SWII 051	5 Kg	0.1 gm	240 mm X 190 mm
SWII 062	6 Kg	0.2 gm	240 mm X 190 mm
SWII 101	10 Kg	1 gm	240 mm X 190 mm
SWII 105	10 Kg	0.5 gm	240 mm X 190 mm
SWII 202	20 Kg	2 gm	240 mm X 190 mm
SWII 201	20 Kg	1 gm	240 mm X 190 mm
SWIID 01 / 02	1 / 2 Kg	0.1 / 0.2 gm	240 mm X 190 mm
SWIID 02 / 05	2 / 5 Kg	0.2 / 0.5 gm	240 mm X 190 mm
SWIID 03 / 06	3 / 6 Kg	0.1 / 0.2 gm	240 mm X 190 mm

Specifications:

Operating temperature: 10°C to 60°C
Storage temperature: -10°C to 60°C
Humidity: 10% to 95 % relative
Power supply: 230 volt / 50 Hz ± 5%
Power consumption: Less than 10 watts
Display: 7 segment bright LED display /LCD display
All models & designs are subjected to change
All models are approved by Department of Weights & Measure, Govt. of India

Features:

Advanced micro controller based system
Overload protection for safety
Most precise and best quality components
Stainless steel pan
Bright (red / green) LED display
Auto calibration
Liter / Kg conversion
Standby mode for long time backup (battery saving)
AC / DC indicator
RS 232 port for computer / printer Interfacing
Hook facility available for suspended weighing as per requirement
Dual display on 360° revolving pole or back side for easy reading

Applications:

Jewelery
Laboratories
Chemical, pharmaceutical industries
School & colleges
Packing units

Precision Meets Portability

Our digital weighing scale offers high accuracy of 1 g and a capacity of up to 30 kg. Its compact build and lightweight design make it portable, ideal for a variety of environments including retail stores, grocery shops, and laboratories. The sturdy stainless steel platform ensures durability while the large backlit LCD enhances visibility in any lighting condition.

User-Friendly Operation & Features

Operating this weighing scale is intuitive thanks to clearly marked buttons for tare, power, and unit selection. The auto-zero and overload protection functions ensure accurate and safe weight measurements each time. The device can be powered by both AC supply and a rechargeable battery, ensuring flexibility and convenience for users.

Maintenance and Versatility

Cleaning is simple due to the smooth surface design, while the IP20 rating offers essential dust resistance. This scale is suitable for a range of tasks, from precise laboratory measurements to everyday grocery weighing, and even as a counting scale in trading or distribution environments.

FAQs of Digital Weighing Scale:

Q: How do you calibrate this digital weighing scale?

A: Calibration is performed externally, meaning youll need a certified calibration weight. Follow the instructions in the user manual to enter calibration mode and adjust settings as needed for accurate results.

Q: What is the process for switching between measurement units?

A: To switch between grams and kilograms, simply press the Unit Select button on the scales control panel. The display will indicate the current unit in use.

Q: When is it best to use the tare function on this scale?

A: Use the tare function whenever you want to measure net weight without including the weight of a container or packaging. Place the container on the platform, press Tare, and then add your item for precise measurement.

Q: Where can this weighing scale be used effectively?

A: This scale is suited for retail outlets, grocery stores, laboratories, and any setting requiring accurate weight measurement up to 30 kg. Its portability and robust construction make it a reliable choice for multiple commercial and industrial environments.

Q: What are the benefits of the rechargeable battery feature?

A: The built-in rechargeable battery provides up to 72 hours of operation, enabling use in locations with unstable power supply or during mobile applications, without constant need for AC power.

Q: How does the overload protection function work?

A: The overload protection system prevents damage by warning when the load exceeds the 30 kg maximum, ensuring the scales longevity and consistent measurement accuracy.

Q: What maintenance steps are recommended for this weighing scale?

A: Regularly wipe the stainless steel and ABS platform with a damp cloth to maintain cleanliness. Avoid exposure to excessive humidity and always store the scale in a dust-free environment for optimal performance.
